Electrical | |
Power supply | 415V / 50Hz / 3Ph |
Rated current | 32 amps |
Motor | 4 kW |
Motor speed | 2800 rpm |
Mechanical | |
Package dimensions (L x W x H) | 1200 mm x 600 mm x 1400 mm |
Weight (dry) | 350 kg |
Flow @ head | 2 L/s @ 25m |
Shut off head | 29 m |
Working pressure | 800 kPa |
Suction / Discharge | 1 ¼ inch / 1 inch |
By submitting this enquiry you agree to Coates Hire's Communication Terms & Conditions.
Electrical | |
Power supply | 415V / 50Hz / 3Ph |
Rated current | 32 amps |
Motor | 4 kW |
Motor speed | 2900 rpm |
Mechanical | |
Package dimensions (L x W x H) | 1200 mm x 600 mm x 1400 mm |
Weight (dry) | 440 kg |
Flow @ head | 4 L/s @ 32m |
Shut off head | 34.5 m |
Efficient | 52.9% |
Diameter | 160 mm |
Working pressure | 1600 kPa |
Suction / Discharge | 2 inch / 1 ¼ inch |
By submitting this enquiry you agree to Coates Hire's Communication Terms & Conditions.
Electrical | |
Power supply | 415V / 50Hz / 3Ph |
Rated current | 32 amps |
Motor | 4 kW |
Motor speed | 2900 rpm |
Mechanical | |
Package dimensions (L x W x H) | 1200 mm x 600 mm x 1400 mm |
Weight (dry) | 472 kg |
Flow @ head | 8.02 L/s @ 25.1m |
Shut off head | 29.2 m |
Efficient | 60.9% |
Diameter | 112 mm |
Working pressure | 1600 kPa |
Suction / Discharge | 2 ½ inch / 1 ½ inch |
By submitting this enquiry you agree to Coates Hire's Communication Terms & Conditions.
Electrical | |
Power supply | 415V / 50Hz / 3Ph |
Rated current | 32 amps |
Motor | 7.5 kW |
Motor speed | 2900 rpm |
Mechanical | |
Package dimensions (L x W x H) | 1200 mm x 600 mm x 1400 mm |
Weight (dry) | 507 kg |
Flow @ head | 16.5 L/s @ 28m |
Shut off head | 34 m |
Efficient | 76% |
Diameter | 155 mm |
Working pressure | 1600 kPa |
Suction / Discharge | 2 ½ inch / 1 ½ inch |
By submitting this enquiry you agree to Coates Hire's Communication Terms & Conditions.
Electrical | |
Power supply | 415V / 50Hz / 3Ph |
Rated current | 32 amps |
Motor | 18.5 kW |
Motor speed | 2900 rpm |
Mechanical | |
Package dimensions (L x W x H) | 1500 mm x 600 mm x 1450 mm |
Weight (dry) | 680 kg |
Flow @ head | 32.7 L/s @ 32 m |
Shut off head | 42 m |
Efficient | 80.6% |
Diameter | 132 mm |
Working pressure | 1600 kPa |
Suction / Discharge | 3 inch / 2 ½ inch |
By submitting this enquiry you agree to Coates Hire's Communication Terms & Conditions.
Electrical | |
Power supply | 415V / 50Hz / 3Ph |
Rated current | 32 amps |
Motor | 18.5 kW |
Motor speed | 2900 rpm |
Mechanical | |
Package dimensions (L x W x H) | 1500 mm x 600 mm x 1650 mm |
Weight (dry) | 750 kg |
Flow @ head | 32 L/s @ 32 m |
Shut off head | 42 m |
Efficient | 80.6% |
Diameter | 132 mm |
Working pressure | 1600 kPa |
Suction / Discharge | 3 inch / 2 ½ inch |
By submitting this enquiry you agree to Coates Hire's Communication Terms & Conditions.
Where can I get a datasheet for a HVAC pump?
Contact the Coates team on 13 15 52 for a datasheet containing detailed product specifications.
How much does it cost to hire a HVAC pump?
Hire rates vary depending on hire length and running hours per day. Contact the Coates team on 13 15 52 for a quote.
What terrain can a HVAC pump be used on?
Our HVAC pumps are mounted on a robust galvanised steel skid, making them suitable for all types of terrain.
How can I transport a HVAC pump?
Our pumps are equipped with forklift slots, lifting points and tie down points for easy transport.
