Power Source |
|
Batteries | 8 x 6V, 370 A-h |
Electrical System | 48 Volts DC |
Performance Data |
|
Drive Speed - Platform Lowered | 4.80 km/h / 3 mph |
Gradeability - 2WD | 30 % |
Platform Capacity | 230 kg / 507.1 lb |
Platform Capacity - Unrestricted | 226.80 kg / 500 lb |
Swing | 360 Degrees |
Swing Type | Non-Continuous |
Turning Radius - Outside | 3.15 m / 10.3 ft |
Dimensional Data |
|
Ground Clearance | 0.13 m / 5 in. |
Machine Height | 1.97 m / 6.5 ft |
Machine Length | 6.71 m / 22 ft |
Machine Width | 1.50 m / 4.9 ft |
Platform Dimension A | 0.76 m / 2.5 ft |
Platform Dimension B | 1.22 m / 4 ft |
Platform Height | 12.19 m / 40 ft |
Tailswing | 0.1 m / 4 in |
Tyre Size | 25 x 7 x 12 Solid Non-marking |
Wheelbase | 2.01 m / 6.6 ft |
General Specifications |
|
Capacity - Hydraulic Reservoir | 20 L / 5.3 gal. |
Machine Weight | 6759 kg / 14901 lb |
Reach Specifications |
|
Working Height | 14.19 m / 46.6 ft |
Working Outreach | 7.48 m / 24.5 ft |
Horizontal Jib Rotation | 180 Degrees |
Horizontal Outreach | 6.83 m / 22.4 ft |
Platform Height | 12.19 m / 40 ft |
Up and Over Height | 6.55 m / 21.5 ft |
