Power Source | |
Batteries | 8 x 6V, 370 A-h |
Charger | 20 A SCR Automatic |
General Specifications | |
Brakes | Spring Applied Hyd Released Discs |
Capacity - Hydraulic Reservoir | 32 L / 8.5 gal. |
Ground Bearing Pressure | 4.30 Kg/cm2 |
Hydraulic Pump | Single Section Gear Pump |
Machine Weight | 5300 kg / 11684.5 lb |
Performance Data | |
Drive Speed - Platform Elevated | 0.80 km/h / 0.5 mph |
Drive Speed - Platform Lowered | 4.80 km/h / 3 mph |
Gradeability - 2WD | 35 % |
Gradeability - 4WD | 45 % |
Lift Time | 54 sec. |
Lower Time | 50 sec. |
Maximum Drive Height | 9.14 m / 30 ft |
Maximum Lift Height | 12.19 m / 40 ft |
Outriggers or Stabilizers | No |
Platform Capacity | 360 kg / 793.7 lb |
Platform Capacity - Extension | 120 kg / 264.6 lb |
Turning Radius - Outside | 4.88 m / 16 ft |
Dimensional Data | |
Ground Clearance | 0.2 m / 8 in. |
Machine Height | 2.83 m / 9.3 ft |
Machine Height - Rails Folded | 2.04 m / 6.7 ft |
Machine Length | 3.15 m / 10.3 ft |
Machine Width | 1.75 m / 5.7 ft |
Platform Dimension A | 1.65 m / 5.4 ft |
Platform Dimension B | 2.92 m / 9.6 ft |
Platform Extension Length | 0.91 m / 3 ft |
Platform Height | 12.19 m / 40 ft |
Platform Height - Lowered | 1.73 m / 5.7 ft |
Platform Railing Height | 1.10 m / 3.6 ft |
Tyre Size | 240/55 x 17.5 Non-Marking |
Wheelbase | 2.32 m / 7.6 ft |
Reach Specifications | |
Platform Height | 12.19 m / 40 ft |
Working Height | 14.19 m / 46.6 ft |
