PLATFORM | |
Working Height |
60’ 18.3m |
Platform Height |
54’ 16.5m |
Size |
30” x 67.5” 780 x 1717mm |
Capacity |
500lbs 227kgs |
Construction |
Steel |
MACHINE DIMENSIONS | |
Stowed Length |
22’ 6.7m |
Stowed Height |
8’ 4” 2.58m |
Wheelbase |
8’ 5” 2.6m |
Width |
7’ 4” 2.27m |
Ground Clearance |
1’ 4” 440mm |
Weight |
13,999lbs 6350kgs |
Tire Size |
14 x 17.5 x 14 ply (foam filled) |
PERFORMANCE | |
Power Source |
Diesel Engine |
Fuel Capacity |
100 litres |
Hydraulic Capacity |
100 litres |
DRIVE SPEED | |
Elevated |
1mph 1.6km/h |
Stowed Max |
2.5mph 4km/h |
Gradeability |
40% |
Horizontal Reach |
46’ 14m |
